Symmetric B30-7W-Triac-A100-H10
Black - 9680212
This Symmetric LED lighting module combines a sleek black aluminum body with a compact 10 cm cubic design, ideal for indoor architectural applications. It features a 7W LED light source with a high CRI above 90 and a wide 100° beam angle, delivering quality illumination with excellent color rendering. The module is dimmable via Triac controls and adjustable for precise light positioning. Its surface mounting and acrylic diffuser ensure easy installation and soft light diffusion. Rated IP20 and IK4, it suits protected indoor environments requiring reliable, stylish lighting.
Dimming Type
Triac
Dimmable
Yes
IP Rating
20
Length (cm)
10
Height (cm)
10
Width (cm)
10
Led Module Replaceable
No
Net Weight (kg)
0.49
EAN
5212017470799
Colour
Black
Material
Aluminum
Diffuser
Acrylic
Adjustable
Yes
IP Rating
20
Mounting Type
Surface
IK Rating
4
Application Environment
Indoor
Mounting Location
Ceiling, Wall
Power (W)
7
CCT (K)
3000
CRI
>90
Dimming Type
Triac
Light Colour Designation
Warm White
Luminus Flux (lm)
275
Luminous Efficacy (lm/w)
39.29
Beam Angle (°)
100
Light Source
LED
SDCM
<3
Current Type
DC
Warranty (Years)
3
Lifetime (Hours)
30000
Class
III
Certificates
CE, UKCA
