On/Off-6W-500mA
9020172
This compact constant current driver accessory provides a stable output of 6W at 500mA, suitable for indoor lighting applications. Measuring 5.8 cm in length, 2.85 cm in width, and 2.1 cm in height, it is designed specifically for use with the Selene family of luminaires. Its IP20 rating ensures protection in indoor environments, making it an ideal component for reliable LED driver performance.
Dimming Type
On / Off
Dimmable
No
IP Rating
20
Length (cm)
8.4
Height (cm)
1.65
Width (cm)
2.05
Additional Information
Input voltage (operating): 198-264VAC. Efficiency: 76 %. Lifetime conditions: >50, 000h@Tc=70°C. Control: On/Off.
EAN
5212017418173
IP Rating
20
Application Environment
Indoor
Power (W)
6
Input Voltage (V)
220-240
Dimming Type
On / Off
Output Voltage (V)
5-12
Output Current (mA)
500
Current Type
AC
Mains Frequency (Hz)
50/60
Max Power (W)
6
Ambient Working Temp.
-20°C to +50°C
Power Factor
0.5
Drivers Efficiency (%)
76
Warranty (Years)
5
Lifetime (Hours)
50000
Class
II
Certificates
CE, UKCA, ENEC
